1. Brief Introduction of Twin Shaft Concrete Mixer

JS double horizontal spindle forced mixer is applicable to large, medium-sized, and small component factories and roads, bridges, water conservancy, ports, and other industrial or civil constructions. It can be used to mix the dry concrete, plastic concrete, fluidity concrete, lightweight aggregate concrete and various mortars.
It is a high efficient machine with extensive applications.

2. Features of Twin Shaft Concrete Mixer
1. The concrete mixer is double horizontal shaft forced type, with the features of short time mixing, fast unloading, mixing evenly and high productivity etc.
2. For dry hard, plastic and various proportions of concrete, can achieve good mixing effect with reliable quality.
3. Cr-hard cast iron blades and plates provide faster mixing and longer service life.
4. Multi-combined sealing by imported components, avoid the cement and slurry contacting the shaft end, extend the service life of the concrete mixer.
5. Adopt the famous international and domestic brand planetary gear reducer, which enjoys the features of small size, high efficiency, and reliable quality.
6. Overweight design, excellent shock absorption.
7. Hydraulic pumps control the discharge gate, with the three points to stay and manual open gate device.
8. Centralized lubrication system uses powerful 380V motor, can quickly inject lubricant to the shaft head.

3. Parts of Twin Shaft Concrete Mixer
Mixing Device
Cr-hard cast iron blades and scrapers provide faster mixing and longer service life
Reducer
Adopt the Italy brand or self-making reducer and parts, with reliable performance, long service life and low noise.
Shaft-end sealing
Multi-combined sealing by imported components, avoid the cement and slurry contacting the shaft end, extend the service life of the concrete mixer.
Electric lubricating oil pump
Supply the grease to four shaft ends respectively with four pump cores. No use of flow divider valve in order to avoid blocking and decrease the workload of maintenance and service.
Discharging system
Hydraulic discharging system, with strong drive force and reliable discharging, discharging door can be opened at any angle; With the function of manual discharging; The discharging door adopts detachable structure, convenient for maintenance.

4. Parameter of Twin Shaft Concrete Mixer

Model	Unit	JS1000	JS1500	JS2000	JS2500	JS3000	JS3500	JS4000
Charging Volume	L	1500	2250	3000	3750	4500	5300	6000
Discharging Volume	L	1000	1500	2000	2500	3000	3500	4000
Max of Aggregate	MM	80/100	80/100	80/100	80/100	80/120	80/120	80/150
Motor Power	KW	18.5x2	30x2	37x2	45x2	55x2	55x2	75x2
Weight	T	5.20	5.80	7.50	8.50	9.20	9.60	12.20
Dimension	MM	2810x2000 x1920	3230x2000 x1920	3460x2320 x2140	3670x2320 x2140	3880x2600 x2200	4100x2600 x2200	4670x2600 x2200
